BlueMap Integration¶

Factions integrates with BlueMap to display faction territories on the BlueMap web interface. BlueMap renders the world in 3D; Factions draws territory as extruded 3D shapes (from world min height up to mapTerritoryMaxY), with unclaimed holes inside faction land shown as cutouts. Popups show faction information when clicking on territory.

Note

For more information about BlueMap, visit the BlueMap Wiki or GitHub.

Shared configuration

Most map-related settings are shared across all map integrations (Dynmap, BlueMap, SquareMap, and Pl3xMap). Only bluemapEnabled and bluemapLogTimeSpent are specific to BlueMap. The shared settings use the map* prefix and are documented below; changing them affects all enabled map integrations.

Features¶

Territory Visualization¶

3D Extruded Shapes: Faction territories displayed as 3D prisms from world min height up to mapTerritoryMaxY
Multi-World Support: Territories shown for all worlds with faction claims
Connected Territory Detection: Adjacent chunks grouped into single polygons with holes for unclaimed areas
Real-Time Updates: Territory changes reflected on the map within 15 seconds
Asynchronous Processing: Updates occur without impacting server performance
Marker Persistence: BlueMap markers are not persistent; Factions re-creates them when BlueMap loads and on each periodic run

Faction Information Popups¶

When clicking on faction territory, detailed information is displayed:

Faction name and description
Leader and member list
Faction age and founded date
Bank balance (if economy integration enabled)
Faction flags in formatted tables
Custom information via macros

Visual Customization¶

Per-Faction Styling: Different factions can have unique colors and styles
Special Faction Styling: SafeZone and WarZone have distinct appearances
Line and Fill Properties: Customizable border/fill colors, opacity, line weight
Layer Management: Factions appear on dedicated marker sets (territory, homes, warps)
Home and Warp Markers: Faction homes and warps displayed with custom icons (BlueMap uses assets/ paths)

Configuration¶

BlueMap-Specific Settings¶

Setting	Default	Description
`bluemapEnabled`	`true`	Enable/disable the BlueMap integration
`bluemapLogTimeSpent`	`false`	Log BlueMap update timing to console (debug)

Map Settings (Territory Layer)¶

These settings apply to Dynmap, BlueMap, and SquareMap. For BlueMap, mapTerritoryMaxY is used to cap the top of the extruded territory shapes.

Setting	Default	Description
`mapLayerName`	`"Factions"`	Name of the territory (claims) layer in the map's layer menu
`mapLayerHiddenByDefault`	`false`	Whether the territory layer is hidden when first loading the map
`mapLayerPriority`	`2`	Territory layer ordering priority (lower numbers appear first)
`mapLayerMinimumZoom`	`0`	Minimum zoom level before territory layer becomes visible (0 = always visible)
`mapTerritoryMaxY`	`320`	Maximum Y level for territory extrusion; claim areas are drawn from world min height up to this value

Map Settings (Home Warp Layer)¶

Setting	Default	Description
`mapShowHomeWarp`	`false`	Enable/disable displaying Faction Homes on the map
`mapLayerNameHome`	`"Faction Homes"`	Name of the Faction Homes layer
`mapLayerHiddenByDefaultHome`	`true`	Whether the Faction Homes layer is hidden when first loading the map
`mapLayerPriorityHome`	`3`	Faction Homes layer ordering priority
`mapLayerMinimumZoomHome`	`0`	Minimum zoom level before Faction Homes layer becomes visible
`mapWarpHomeIcon`	`"redflag"`	Icon for Faction Homes. The default setting will not work for BlueMap - use a filename or path relative to the root of the Bluemap "web" directory, like `assets/poi.svg`

Map Settings (Other Warps Layer)¶

Setting	Default	Description
`mapShowOtherWarps`	`false`	Enable/disable displaying Faction Warps (non-home) on the map
`mapLayerNameWarps`	`"Faction Warps"`	Name of the Faction Warps layer
`mapLayerHiddenByDefaultWarps`	`true`	Whether the Faction Warps layer is hidden when first loading the map
`mapLayerPriorityWarps`	`4`	Faction Warps layer ordering priority
`mapLayerMinimumZoomWarps`	`0`	Minimum zoom level before Faction Warps layer becomes visible
`mapWarpOtherIcon`	`"greenflag"`	Icon for Faction Warps. The default setting will not work for BlueMap - use a filename or path relative to the root of the Bluemap "web" directory, like `assets/poi.svg`

Faction Information Display¶

The faction popup description is customizable using the mapDescriptionWindowFormat setting. It is standard HTML that supports various macros (placeholders) that will be replaced with real information about the faction:

Macro	Description
`%name%`	Faction name
`%description%`	Faction description
`%players%`	List of faction members
`%players.count%`	Number of players in the faction
`%players.leader%`	Faction leader name
`%power%`	Current Faction power
`%maxpower%`	Max Faction power
`%claims%`	Number of claimed chunks
`%age%`	How long the faction has existed
`%money%`	Faction bank balance
`%flags.table1%` - `%flags.table10%`	Faction flags in 1-10 column tables
`%flags.map%`	All faction flags as a map (flag: value)

Dynamic Flag Macros:

For each faction flag (like monsters, pvp, explosions, etc.), you can use:

%flagname.bool% - The boolean value (true/false) of if it is enabled/disabled
%flagname.boolcolor% - Boolean value with green/red color formatting
%flagname.color% - Flag name with green/red color formatting

Flag Table System:

The %flags.tableX% macros automatically arrange all faction flags into columns separated with a pipe delimiter |. For example:

%flags.table1% creates a single-column list
%flags.table3% creates a 3-column list (default used in template)
%flags.table5% creates a 5-column list for more compact display

The default configuration displays flags with color coding (it uses the %flagname.boolcolor% macro). The setting mapUseDarkModeColors toggles brighter green/red for dark map themes.

Default Description Template:

The description template uses HTML (setting mapDescriptionWindowFormat):

<div class='infowindow'>
  <div>
    <div style='font-weight: bold; font-size: 150%;'>%name%</div>
  </div>
  <div style='margin-bottom:7px;padding-bottom: 7px;border-bottom: 1px solid gray;'>
    <div style='font-style: italic; font-size: 110%;'>%description%</div>
  </div>
  <div>
    <div><strong>Leader:</strong> %players.leader%</div>
    <div><strong>Members:</strong> %players%</div>
  </div>
  <div style='margin-bottom:7px;padding-bottom: 7px;border-bottom: 1px solid gray;'>
    <div><strong>Age:</strong> %age%</div>
    <div><strong>Bank:</strong> %money%</div>
  </div>
  <div>
    <div style='font-weight: bold;'>Flags:</div>
    <div>%flags.table3%</div>
  </div>
</div>

Visibility Control¶

Setting	Description
`mapVisibleFactions`	Faction names/UUIDs to show (empty = show all). Use `world:<worldname>` to show all factions in a world
`mapHiddenFactions`	Faction names/UUIDs to hide. Use `world:<worldname>` to hide a world
`mapShowMoneyInDescription`	Enable the `%money%` macro (requires thread-safe economy)
`mapUseDarkModeColors`	Use brighter green/red in description for dark map themes

World-Specific Visibility:

Add world:<worldname> to show/hide all factions in a specific world
Faction specification supports both names and UUIDs

{
  "mapVisibleFactions": ["MyFaction", "world:survival"],
  "mapHiddenFactions": ["TempFaction", "world:creative"]
}

Visual Styling¶

Default Style¶

By default, factions use either the Faction default colors or the map default colors. The primary color is used as the fill color, and the secondary color is used as the line color.

mapDefaultLineColor / mapDefaultFillColor: Optional hex overrides (e.g. "#00FF00"). If null/empty, the defaultFactionSecondaryColor and defaultFactionPrimaryColor from the main Factions config will be used instead.
mapUseFactionColors: When true, territory colors come from the faction's colors (set via /f color). When false, only the map defaults and per-faction overrides are used.

Global default line/fill opacity, line weight, and boost are defined in mapDefaultStyle. This object cannot be edited with /f config; edit mstore/factions_mconf/instance.json directly if you need to change default opacity or weight.

Per-Faction Overrides¶

The mapFactionStyleOverrides setting allows overriding style for specific factions. These overrides take precedence over faction colors and map defaults.

This setting cannot be configured with the /f config command - it must be edited manually in the mstore/factions_mconf/instance.json file.

Note

Comments have been added in the example below to explain values; do not add comments in your actual JSON file or it may cause errors.

{
  "mapFactionStyleOverrides": {
    "MyFactionName": { // The name of the faction - spelling must be exact
      "lineColor": "#0000FF", // The border color of faction territory
      "fillColor": "#0000FF", // The fill color of faction territory (inside the border)
      "lineOpacity": 1.0, // The opacity of the border
      "fillOpacity": 0.5, // The opacity of the fill (inside the border)
      "lineWeight": 3, // The thickness of the border line
      "boost": true // Whether to boost the faction layer to be on top of other layers
    }
  }
}

Default Special Faction Styles:

SafeZone and WarZone have built-in overrides (can be overridden again in mapFactionStyleOverrides):

"SafeZone": {
  "lineColor": "#FFAA00",
  "fillColor": "#FFAA00",
  "boost": false
},
"WarZone": {
  "lineColor": "#FF0000",
  "fillColor": "#FF0000",
  "boost": false
}

Troubleshooting¶

Common Issues¶

Territories not showing:

Check bluemapEnabled is true
Verify BlueMap is installed and running; run /bluemap reload if needed
Check mapVisibleFactions and mapHiddenFactions
Ensure factions have claimed territory

Performance problems:

Enable bluemapLogTimeSpent to identify bottlenecks
Limit visibility with mapVisibleFactions or mapHiddenFactions
Check server console for errors

Icons not showing for homes/warps:

Icons from the config are loaded relative to the root path of the BlueMap web directory (root folder of the server). Ensure the file/path exists.

Money not displaying:

Set mapShowMoneyInDescription to true and ensure economy is thread-safe
Verify Vault integration and faction bank settings

Wrong colors/styles:

Verify mapUseFactionColors and faction names in mapFactionStyleOverrides
Use valid hex color codes (e.g. #RRGGBB)

Debug Options¶

Set bluemapLogTimeSpent to true in the config to log update timing to the console.
